3M X 2.1M Flat Pack Storage Container

The Eoslift CPD30 4-Wheel Electric Forklift is a high-capacity, reliable solution designed for heavy-duty material handling. With a lifting capacity of up to 6,600 lbs, this forklift combines robust construction, advanced electric power, and ergonomic design to optimize performance in warehouses, distribution centers, and industrial environments.

Key Features

• Electric Counterbalance Forklift – Efficient, emission-free operation.
• AC Driving Motor with CURTIS Controller – Smooth and precise control for better maneuverability.
• High-Capacity Battery – 80V 400Ah lead-acid battery for extended work hours.
• Hydraulic Steering & Pneumatic Tires – Stable, comfortable, and safe handling.
• Ergonomic Luxury Seat – Adjustable anti-fatigue seat with curved mirror.
• Intelligent LED Display – Large, clear screen for easy monitoring and intuitive interface.
• Safety Features – AC drive system, hand brake, foot hydraulic pedal brake, quick cut-off valve, and lowering speed limit valve.

Performance Highlights

• Compact Front Overhang Design – Improves stability and reduces energy consumption.
• Horizontal Motor & Low-Battery Placement – Enhances driving stability.
• High-Efficiency Drive Axle Box – Better climbing ability, reduced noise, and lower energy use.
• Optimized Lifting & Driving Speeds – 11.81 / 18.89 in/s lifting speed, 6.21 m/h driving speed (load/unload).
• Multi-Angle Adjustable Seat – Ensures operator comfort during long shifts.

Specifications

• Model: CPD30
• Mast Type: Duplex
• Power Type: Battery
• Operation Type: Seated
• Rated Capacity: 6,613.87 lbs
• Load Center: 19 in.
• Wheelbase: 54 in.
• Service Weight (inc. battery): 6,393 lbs
• Tires: Pneumatic (Load: 5.11~8.07 in, Drive: 6.29 x 9.05 in)
• Number of Wheels: 2x/2
• Wheel Tread, Load Side: 36.6 in
• Mast Closed Height: 78.54 in
• Free Lift Height: 5.31 in
• Lift Height: 118.11 in
• Extended Mast Height w/ Load-Backrest: 158.66 in
• Overall Dimensions (L x W): 126.18 in x 43.7 in
• Fork Size (L x W x H): 42.12 in x 3.93 in x 1.37 in
• Fork Outside Width: 8.74–39.37 in
• Mast Ground Clearance: 3.34 in
• Turning Radius: 78.74 in

Performance & Power

• Driving Speed (load/unload): 6.21 m/h
• Lifting Speed (load/unload): 11.81 / 18.89 in/s
• Lowering Speed (load/unload): 14.96 / 14.17 in/s
• Max Gradeability (load/unload, S2-5min): 14/15%
• Drive Motor: AC 6.8 kW
• Lifting Motor: DC 8.2 kW
• Battery Voltage/Capacity: 48 V / 400 Ah
• Battery Weight: 1,421.98 lbs
• Steering System: Hydraulic

Why Choose the Eoslift CPD30?

With 4-wheel stability, precise controls, and ergonomic design, the Eoslift CPD30 ensures safe and efficient handling of heavy loads in tight spaces. Its durable construction and energy-efficient electric powertrain make it ideal for high-demand industrial applications, increasing productivity while reducing operational costs.

Available at stoolby.com

Upgrade your material handling capabilities with the Eoslift CPD30 4-Wheel Electric Forklift—powerful, reliable, and designed for peak performance. Explore more at stoolby.com and bring efficiency and safety to your warehouse or industrial operations.
