70ST Single Axle Tilt Trailer

Overview

The 70ST Single Axle Tilt Trailer is a compact and budget-friendly equipment trailer designed for hauling smaller vehicles, light-duty equipment, ATVs, and compact machinery. With its hydraulic tilt deck system, durable steel construction, and low loading angle, it offers fast and easy loading without the need for ramps.

Key Features

• Hydraulic dampening tilt deck system
• 7,000 lb single drop axle
• 12° tilt angle for easier loading
• 5″ channel steel frame
• Rub rail along both sides
• LED recessed trailer lighting
• Quick-lubricating hubs
• Diamond plate knife edge for smooth loading
• Adjustable forged coupler
• 8,000 lb drop-leg jack

Construction & Design

Frame

• Heavy-duty 5″ channel frame
• 3″ channel cross-members on 16″ centers

Tilt Deck

• Hydraulic dampening system with deck lock
• Low-angle loading design
• Tilt deck dimensions:
  • 81″ wide
  • 1/4″ diamond plate knife edge

Flooring

• Standard APEX fortified lumber floor
• Optional:
  • Blackwood Pro rubber-infused lumber
  • Diamond plate steel floor

Axles & Suspension

Axle

• 1 x 7,000 lb drop axle
• Quick-lube hubs

Suspension

• Multi-leaf slipper spring with equalizer

Tires

• ST235/80 R-16 Load Range E radial tires
• Optional LR-G tire upgrade

Lighting & Wiring

• Recessed LED lighting
• Sealed cold-weather wiring harness
• 7-way RV trailer plug

Safety Features

• Forward self-adjusting electric brakes
• Complete breakaway system with charger
• Grade 70 safety chains
• Adjustable forged coupler
• Front stop rail

Available Models

70ST-13

• Bed Length: 13 ft
• Bed Width: 83 in.
• Empty Weight: 2,110 lbs
• Cargo Capacity: 4,890 lbs
• GVWR: 7,000 lbs

70ST-16

• Bed Length: 16 ft
• Bed Width: 83 in.
• Empty Weight: 2,310 lbs
• Cargo Capacity: 4,690 lbs
• GVWR: 7,000 lbs

Standard Equipment

• Adjustable forged coupler
• 8,000 lb drop-leg jack
• Stake pockets along both sides
• Rub rail
• 4 heavy-duty D-rings
• Removable diamond plate fenders
• LED DOT lighting
• Hydraulic tilt system

Optional Upgrades

• 2-5/16″ adjustable coupler
• Spare tire & wheel
• LR-G tire upgrade
• Extra D-rings
• Steel flooring
• Blackwood Pro flooring

Best Uses

• ATVs and UTVs
• Compact tractors
• Small skid steers
• Lawn equipment
• Golf carts
• Light-duty machinery hauling

Why Choose the 70ST Tilt Trailer?

The 70ST Single Axle Tilt Trailer is ideal for users wanting:

• Easy loading without ramps
• Reliable light-duty hauling
• Lower loading angles
• Durable construction
• Budget-friendly performance

Its tilt deck system and compact design make it an excellent choice for transporting smaller equipment efficiently and safely.
