Big Tex Tandem Axle Pipe Top Utility Trailer | 60PI

The 25DU Tandem Dual Gooseneck Dump Trailer is built for handling massive payloads with strength, stability, and reliability. Designed for construction, landscaping, and heavy-duty hauling applications, this trailer features reinforced construction, dual tires, and a high-capacity dump bed for demanding jobs.

With a cargo capacity of 17,830 lbs., the 25DU is ideal for transporting heavy machinery, gravel, sand, debris, and other large loads. The 48-inch tall dump sides and 45° dump angle make unloading fast and efficient, while the gooseneck design improves towing stability and load distribution.

The trailer is equipped with two 10,000 lb. cambered axles with oil bath hubs and forward self-adjusting electric brakes on both axles for dependable performance. Heavy-duty suspension, a 12-inch I-beam frame, and 3-inch channel cross-members provide outstanding structural strength for long-lasting durability.

Additional features include recessed LED lighting, sealed cold-weather wiring harness, dual drop-leg jacks, lockable pump and battery box, rear stabilizer stands, double rear doors, integrated D-rings, stake pockets, and a complete breakaway system. The power up/gravity down hydraulic system ensures smooth dumping operation, while the fully formed tarp shroud and roll tarp system help secure loads during transport.

Features:

• Tandem dual gooseneck dump trailer
• 17,830 lb. cargo capacity
• 45° dump angle for efficient unloading
• 48 in. tall dump sides with formed channel supports
• Heavy-duty 12 in. I-beam frame construction
• Dual 10,000 lb. cambered axles with oil bath hubs
• Forward self-adjusting electric brakes on both axles
• Dual 12,000 lb. drop-leg jacks
• Recessed LED lighting system
• Sealed modular cold-weather wiring harness
• Stake pockets along both sides
• Integrated 5/8 in. D-rings for cargo security
• Double rear doors
• Lockable pump and battery box
• Power up/gravity down hydraulic system
• Rear stabilizer stands
• Fully formed tarp shroud with roll tarp system
• Black professional finish with primer

Specifications:

• Model: 25DU-20
• Pull Type: Gooseneck
• GVWR: 25,000 lbs.
• GAWR (Each Axle): 10,000 lbs.
• Empty Weight: 8,070 lbs.
• Cargo Capacity: 17,830 lbs.
• Bed Length: 20 ft
• Bed Width: 92 in.
• Tongue Length: 98-1/4 in.
• Tires: ST235/80 R-16 Load Range E Radial Tires (Dual)
• Coupler: Adjustable 2-5/16 in. Gooseneck Coupler
• Floor Material: 10 Gauge Smooth Steel

Available now at Stoolby.com
